E-Lady / ASSLJ
商品編號：ASSLJ
E-Lady MY27
馬達系統: Shimano
電池: Shimano
輪胎: Schwalbe Marathon E-plus HS498 55-622
新產品研發中
馬達系統: Shimano
電池: Shimano
輪胎: Schwalbe Marathon E-plus HS498 55-622
新產品研發中
ASSLJ
ASSLJ 是一款兼具優雅設計與可靠性能的電動自行車，專為舒適的城市騎乘與日常通勤而打造。搭載 Shimano 電動系統，提供順暢且自然的踩踏助力，滿足日常通勤所需。搭配 Shimano 電池系統，提供穩定可靠的續航表現；Schwalbe Marathon E-Plus HS498 55-622 輪胎則具備優異的耐用性與防刺性能，並提供穩定舒適的騎乘體驗。
| System | Shimano | |
| Battery | Shimano | |
| Travel | 63 mm | |
| Headset | 1.5” Taper ( 44 mm / 56 mm ), Semi | |
| Seatpost | 30.9 mm | |
| Rear Axle | 10 x 135 mm | |
| Tire | Schwalbe Marathon E-plus HS498 55-622 | |
| Direct Mount | 180 mm | |
| Crankset | SM_CRE80_44T (Single Chainguard) | |
| Material | 6061 | |
| Manufacture Base | Vietnam | |
| Note |
Chain Line: 50 mm |
|
| Size | 420 | 460 | 510 | 560 |
| TT Length (A) | 590 | 595 | 605 | 615 |
| Reach | 402.24 | 407.24 | 414.48 | 421.73 |
| HT Angle (B) | 68.5 | |||
| ST Angle (C) | 73.5 | |||
| Stack | 633.87 | 643.18 | 652.48 | |
| W.B (D) | 1138.72 | 1143.72 | 1154.63 | 1165.53 |
| RC (E) | 475 | |||
| BB Drop (F) | 75 | |||
| Fork Offset (G) | 44 | |||
| HT Length (H) | 140 | 150 | 160 | |
| FC | 673.86 | 678.83 | 689.67 | 700.52 |
